HF1-Series High Flow Filter Cartridge

HydraPure HF1-Series high flow filter cartridges are
constructed of a lofted polypropylene structure, with a large
diameter of 6 inches / 152 mm. It is coreless, single open
ended with an inside to out flow pattern. The large diameter
with a big filter area ensures to reduce the number of filter
cartridges and the dimension of housing required. The long
service life and high flow rate result in low investment and
less manpower in many applications. Compatible fit with
Pall®High-Flow series.

Features

• · Manufactured with FDA certified polypropylene
• · Multi-layer structure, higher effective filtration area and higher dirt holding capacity, longer service life
• · 100% Polypropylene media for broad process fluid compatibility
• · Filter rating ranges from 0.5 μm to 100 μm to meet different filtration requirements
• · 20″, 40″ and 60″ are available in length
